Description |
Unit |
LF-2000T |
LF-2500T |
LF-3500T |
|||
|
Injection
Unit |
|||||||
|
Screw
Diameter |
mm |
150 |
160 |
160 |
175 |
175 |
190 |
|
Theoretical
Injection Volume |
cm3 |
17663 |
20096 |
20096 |
24040 |
27645 |
32590 |
|
Injection
Pressure |
kg/cm2 |
2022 |
1777 |
1777 |
1574 |
2103 |
1783 |
|
Injection
Rate |
cm3/sec |
1238 |
1408 |
1408 |
1685 |
1501 |
1770 |
|
Plasticizing
Capacity PS |
Kg/hr |
637 |
823 |
1144 |
1738 |
1580 |
2113 |
|
Shot
Weight |
grams |
14836 |
16880 |
16880 |
20193 |
23220 |
27375 |
|
Screw
Rotation |
rpm |
92.5 |
92.5 |
115 |
|||
|
CLAMPING
UNIT |
|||||||
|
Distance
Between Tie Bars(HxV) |
mm |
1650 x 1400 |
1900 x 1800 |
2200 x 2000 |
|||
|
Mold
Platen |
mm |
2485 x 2235 |
2700 x 2600 |
3100 x 2900 |
|||
|
Mold
Height |
mm |
600
X1600 |
850
X1850 |
850
X2000 |
|||
|
Die
Opening Stroke |
mm |
1900 |
2000 |
2300 |
|||
|
Diameter
of Centering Ring |
mm |
150 |
150 |
150 |
|||
|
Ejector
Stroke |
mm |
330 |
400 |
500 |
|||
|
Clamping
Force |
tons |
2000 |
2500 |
3500 |
|||
|
GENERAL
DATA |
|||||||
|
Number
of Heating Zones |
zones |
10 |
10 |
11 |
|||
|
Heating
Capactiy |
kw |
84.7 |
84.7 |
170 |
|||
|
Pump
Driving Motor |
hp |
300 |
300 |
375 |
|||
|
OilTank
Capacity |
L |
4318 |
4760 |
5200 |
|||
|
Machine
size(LxWxH) |
m |
19.2 x 3.3 x
3.3 |
20 x 5.6 x
5 |
21 x 6 x 5.4 |
|||
|
Net
Weight |
kgs |
160000 |
230000 |
290000 |
|||
