| SPECIFICATION | |||
| Injection Unit | VPD-40 |
VPD-60 |
VPD-100 |
| Diameter of Inj. Planger (mm) | 22 |
32 |
38 |
| Injection Stroke (mm) | 180 |
228 |
228 |
| Actual Shot weight (P.S.) (Gm.) | 40 |
60 |
100 |
| Max. Pressure on Material (Bar) | 1150 |
1250 |
1200 |
| Heating Load (k.w.) | 1.5 |
2 |
2.5 |
| Clamping Unit | Direct | Direct | Direct |
| Clamping force (TON) | 12.5 | 16.5 | 19 |
| Mold Opening (m.m.) | 205 | 228 | 250 |
| Mini & Max Mold Thickness (mm) | 80 x 180 | 100 x 225 | 125 x 250 |
| Mold Size | 125 x 125 | 175 x 175 | 200 x 200 |
| Daylight Opening (mm) | 305 | 353 | 400 |
| Power Unit | |||
| MOTOR (Pump Drive) (H.P.) | 3H.P. | 5H.P. | 7.5H.P. |
| Working Pressure (Bar) | 140 | 140 | 140 |
| Total Installed Power (K.W.) | 3.75 | 5.75 | 7.5 |
| Hydraulic Oil Cap. Ltrs. | 80 | 125 | 150 |
 |
|||
