ARSHAD ELECTRONICS PRIVATE LIMITED was established in 1971. We have pioneered the Corona Discharge Treating
System in India. Today we have over 4000 Installation all over India and the world including the largest
unit of 19 KW for 3 meters wide BOPP Plant. As a result of our extensive Research & Development, experience
and confidence of our customers in our products, we are now the leading manufactures of Corona Discharge
Treaters in India.
Our main interest focuses on assisting our customers in solving their treatment problems and to provide them
with practical solutions for their requirements along with prompt service and regular maintenance at all times.
As market leaders it has been our constant endeavor to innovate and diversify into new fields of high technology.
Our strong R&D capability backed by years of experience in this field has helped us to successfully pioneer the
design, manufacture and marketing of Solid State IGBT Induction Cap Sealing Systems in India from 1994 onwards.
We have more than 800 installations all over the India & abroad including the 4 kW units for cap diameters
of 83 mm at the line speeds of 60 CPM.
We have now entered the European Market and will be exporting the Induction Cap Sealing Systems in the UK and other countries
 |
 |
Our Range of products for the Plastic & Packaging Industry include:
'Fluxomatic' Corona Discharge Treater:
Used to increase the Dyne Level of plastic films for Printing, Lamination and Coating.
Corona Treaters for Monoloyer Extruders
 |
Specification of Generator
Input Voltage: 230 Volts Single Phase
Output Voltage: 10-15 Kvolts
Output Power: 1 Kw-3Kw
Output Frequency: 10-30 Khz |
Electrode System
|
Split Box Treatment Assembly |
|
Treatment Rolls with Pure Silicon Sleeve |
|
Key Type Electrode System for Selective Treatment |
|
Pneumatic Operated Split Box Assembly |
|
Aluminium Construction for light weight |
|
Ozone Extraction System |
Specification of Generation
|
Input Voltage: 230 Volts Single Phase |
|
Output Voltage: 10-15 Kvolts |
|
Output Power: 1 Kw-3 Kw |
|
Output Frequency: 10-30 Khz |
Electrode System
|
Split Treatment Assembly |
|
Treatment Rolls with Pure Silicon Sleeve |
|
Key Type Electrode System for Selective Treatment |
|
Pneumatic Operated Split Box Assembly |
|
Aluminium Construction for light weight |
|
Ozone Extraction System |
Models
ATS 1000-F
It can treat Web Sizes from 12” to 24” for line speed up to 40 mts/min on Both Sides of Extruded Film for Printability
ATS 2000-F
It can treat Web Sizes 24” to 36” for line speeds up to 60 mts/min on Both Sides of Extruded Film for Printability.
ATS 3000-F
It can treat Web Sizes 36” to 52” for line speeds up to 60 mts/min on Both Sides of Extruded Film for Printability
Features
|
IGBT Technology |
|
Power Saving and Highly Efficient |
|
Uniform Treatment |
|
Zero Speed Cut Off Systems |
|
Spark Protection System |
|
Pure Silicon Sleeve |
|
Fault Indicators |
|
Maximum Operator Safety |
|
Corona Treater for Woven Fabric
|
Specification of Generator
Input Voltage: 230 Volts Single Phase Or 415 Volts Three Phase
Output Voltage: 10 Kv
Output Power: 4 Kw
Output Frequency: 20-35 Khz |
Electrodes System for Woven Sacks
|
100 mm Treatment Rollers |
|
100 mm Base Rollers |
|
Unique Electrode System |
|
Automatic Bag feeding System |
|
Aluminum Construction for light weight |
|
Ozone Extraction System |
Electrode System for Woven Roll
|
Split Box Treatment Assembly |
|
Treatment Rolls with Pure Silicon Sleeve |
|
Round Electrode for uniform treatment |
|
Aluminium Construction for light weight |
|
Ozone Extraction System |
Features
|
IGBT Technology |
|
Power Saving and Highly Efficient |
|
Uniform Treatment |
|
Zero Speed Cut Off Systems |
|
Spark Protection System |
|
Pure Silicon Sleeve |
|
Fault Indicators |
|
Maximum Operator Safety |
|
Corona Treaters for Coating and Lamination
|
Specification for Generation |
|
Input Voltage: 230 Volts Single Phase Or 415 Volts Three Phase |
|
Output Voltage: 10-20 Kv |
|
Automatic Bag feeding System |
|
Output Power: 1 Kw-3 Kw |
|
Output Frequency: 10-50 Khz |
Electrode System
|
Bare Roller Assembly |
|
150 mm Base Roller |
|
Unique Electrode System |
|
Aluminium Construction for light weight |
|
Ozone Extraction System |
ATS 5000-CL
It can treat Web Sizes from 50” to 72” for line speeds upto 120 mts/min.
Treatment level of 48 Dynes can be achieved on Single Side.
Models
ATS 2000-CL
It can treat Web Sizes for 12” to 36” for line speeds upto 60 mts/min.
Treatment level of 48 Dynes can be achieved on Single Side.
ATS 300-CL
It can treat Web Sizes for 36” to 50” for line speeds upto 80 mts/min. Treatment level of 48 Dynes can be achieved on Single Side.
Features
|
IGBT Technology |
|
Power Saving and Highly Efficient |
|
Uniform Treatment |
|
Zero Speed Cut Off Systems |
|
Spark Protection System |
|
Pure Silicon Sleeve |
|
Fault Indicators |
|
Maximum Operator Safety |
|
