Manufacturer of Rotomoulding Equipment Machines and Mould

Manufacturer of High Quality Plastic Bag Making Machines
Gujarat Roto is a leading manufacturer of rotomoulding equipment machines and mould in Ahmedabad India. Our manufacturing unit is located in Naroda, Ahmedabad since 2000. We have complete in-house facilities for designing, tooling & production with a team of dedicated engineers to provide with innovative and cost effective solution for rotomoulding requirements. We manufacture Bi-Axial Machine / Open flame Rock - N Roll Machine / Close Flame Rock - N Roll Machine / Pulveriser Machine / Extruder Machine / Scrap cutter / Scrap Grinder / All types of M.S. and S.S. Fabricated moulds
Manufacturing Programmed Machines & Equipments
 Rotational Moulding Machines
    Multi Arm Turret Machines
    Multi Arm Independent Arm Machines
    One Arm/ Two Arm Shuttle Machines
    Rocking Oven Rock "N" Roll Machines
    Open Flame Rock "N" Roll Machines
 Pulverizer for Micro fine Grinding
 Mixers for Dry Blending
 Extruders for Blending / Coloring Compounding
 Scrap Grinders
 Sheet Metal Fabricated Moulds for Roto Moulded Products

Three Arm Bi-Axial Machines

Three Arm Bi-Axial Machines
Salient Features
Specially designed for the energy saving environmental friendly heating chambers with efficient heat transfer technology
State of the art technology in designing the insulation panels for better working environment
Straight-arm with four mould carrying carrier plates for economical working
Environment friendly burners suitable for LPG/ CNG/ OIL/ Duel fuels
Machine controls are equipped with necessary interlocking, safety devices with indicators and alarm
Microprocessor based machine control panel with digital display
Variable speed a/c motors are for major and minor speed controls
Mould indexing facility
Model No. of Arm Fuel Max Capacity Power Required Space Required
GR-1000 3 LPG/Disel 1000 ltr 14 11 x 9 x 4
GR-2000 3 LPG/Disel 2000 ltr 23 12 x 10 x 5
GR-5000 3 LPG/Disel 5000 ltr 35 18 x 16 x 6

Open Flame Rock - N - Roll

Open Flame Rock - N - Roll
Salient Features
Various thicknesses in the product are possible
Special article like Drainage pipes, Boats, up to 6.5 mtr. Can be produced in Rock n Roll comfortably
Most economical with less investment
Sturdy Machine suitable for manufacturing large size hollow products up to 40000 ltrs / 10000 USG Capacity
Speed variable drive for rocking & Rolling for Better control of the product
Microprocessor based machine control panel with digital display
Model Frame Size (mtr) Fuel Power Required PIT Size (mtr)
GRRR-1000 1.5 x 2.5 LPG 3.5 3.5 x 2.0 x 1.5
GRRR-2000 1.8 x 2.8 LPG 5.0 3.8 x 2.3 x 1.7
GRRR-5000 2.5 x 3.0 LPG 8.0 5.0 x 3.0 x 2.0
GRRR-10000 3.0 x 5.0 LPG 12.5 7 x 3.7 x 3.0

Pulverizer

pulverizer
Salient Features
Low Power consumption with high output
Economical production cost with consistence output quality
Low maintenance
Minimum man power
Grinding disk made from grade alloy steel with wear resistance treatment
Cooling Provision for Stationery Disk, Mill body, Duct line, Dearing housing
Vibro feeder/ Auto Servo Control Feeding System
Monitoring of power temperature & control system
Microprocessor based machine control panel with digital display
Model GRP-400 GRP-450
Disc [Dia]mm 400 450
Output Kgs/hr 80-100 120-150
Main motor [HP] 30 40
Mesh size 20-30 20-30
Total power Required 35HP 47 HP
Floor space [mtr] 2.2 x 1.4 x 2.9 2.4 x 1.6 x 3.3

Roto-Moulded Products

Roto-Moulded Products

Roto-Moulded Products
