For Sale - UM - 17531 - W&H Loop Handle Bag Making Machine

Specification

Reference Numbers

UM - 17531

Product

W&H Loop Handle Bag Making Machine

Year Of Manufacture

1997

Location

Europe

Product Details

Type of bag:- Loophandle
Bottom or side seal:- Side seal
Max. seal width:- 850 mm
Min. – Max. bag width:- 250 - 650 mm
Min. – Max bag length:- 250 - 630 mm
Max. number of lanes:- 1
Max. mechanical speed:- 140 m/min
Max. number of cycles:- 130 cycles/minute
Material & Min – Max thickness:- LDPE 35µ-80µ, LLDPE 35µ-50µ
Max. unwind width:- 1400 mm
Max. unwind reel diameter:- 1200 mm
Type of take off / rewind:- Flat
Servo
Edge guide(s)
Photocell
Manuals available
Other information
Length of the loophandle: 350 mm
Width of the loophandle: 30 mm
Including:- Double shrink seam sealing system
Machine can be seen in production
