For Sale - UM - 12077 - Steer Engineering XLPE (Sioplas) Compounding Line

Specification

Reference Numbers

UM - 12077

Product

Steer Engineering XLPE (Sioplas) Compounding Line

Location

Kolkata, India

Product Details

Omega 60 mm co-rotating twin screw extruder L/D 40 with Zambellow Gear Box 150 KW/500 RPM main drive (Yr 2009)
- Gravimetric feeder - 2 Nos (AND Japan)
- Liquid dosing injection pump (Fuji Techno - Japan)
- Hydraulic screen changer
- Under water pelletizer (BKG - Germany)
- Plant with full automation with HMI (Siemens PLC)
- Classifier (ETA - India)
- Hopper dryer - 2 Nos. - 400 Lit and 500 Lit
- Nitrogen plant - MVS Engineering Ltd., India
- Magnetic separator extractor - Swizerland
- Chilling plant 42 TR water cooled screw chiller (Bitzer-Germany) for under water palletizer
- 10 TR Chiller for Barrel / Gear Box Cooling.
- Cooling tower (FRP) - Southern Cooling Towers - India
- R.O. & DM Plant for Barrel cooling and under water palletizer
- Deduster system, Pelletron X PS - Pelletron Corporation, USA
- Pulveriser machine - N.A. Corporation, India
- 1000 Kgs capacity SS Hopper - 2 nos - fitted with knife valve
- SS Liquid Storage Tanks with Load Cell 50kgs capacity- 2 nos
- SS Hopper - 2 nos - 250 kgs capacity
- Pump for liquid circulation inside dosing pump
- Pulsation Damper - Hidracar- Spain
- Air Compressor - Anest Iwata Motherson Ltd., India
- Refrigerant Air Dryer (GEM - India)
- Sealing Machine, 2 nos. - Eewa Engineering Co. Pvt. Ltd., India
- Refrigerant Dehumidifier - White Westinghouse, UK
- Spares: Screw Elements
Barrel Heaters
BKG Cutting Blades
Extra Dosing Pump (Fuji Techno - Japan)
SS 4inch dia Pipes / Blowers for conveying raw materials and finished product.
