For Sale - UM - 4691 - 62 HP Weima Single Shaft Shredder

Specification

Reference Numbers

UM - 4691

Product

62 HP Weima Single Shaft Shredder

Location

USA

Product Details

Model: WLH600S/45 Leopard
- Weima slow speed shredder
- Carbon steel.
- Approximately 368mm (14.4" Diameter) x 24" wide (32) bolt on blade V rotor
- Driven by a 45 kw (60hp) 3/60/460 volt
- 1770 rpm motor
- Approximate: 450-600 rpm rotor speed
- 22-1/2" x 8" Feed opening with a dual chain-link in feed with (2) metal tracks each driven by a 1.1 kw (1/2 hp) gear motor.
- Approximate 7/8" diameter screen holes.
- Set up for blower discharge.
- Includes a control panel with an Allen-bradley powerflex drive and a (2) section
Weima modular vibratory conveyor model WRR 600 approximately 20" wide x 256" long driven by an approximate 3 hp motor. Both built 2006.

(For picture, please see next page)
