For Sale - UM - 4898 - Prandi 2000 mm Cast Film Line

Specification

Reference Numbers

UM - 4898

Product

Prandi 2000 mm Cast Film Line

Year Of Manufacture

1984

Location

Italy

Product Details

- Material: CPP
- Width: 2000 mm

Extruder1 brand: Prandi
- Screw diameter: 160 mm
- Motor power: 213 KW DC; Motor COMER
- Output: 350 kg/hr
- Head automatic: No
- Head internal deckling: No
- Head die width: 2300 mm
- Head thickness control system: Electronic system thickness mesurement

Head notes:
- Head: manual adjustment
- Air and smoke suction by fan and encapsulating hood
- Chill roll: with two cylinders (diameter 750 and 300 mm)
- Width 2400 mm
- Independent thermoregulation units for the two cylinders
- Rubber-covered pressure roller and brush cleaner
- Thickness: 25 to 250 micron
- Edge pinning system by air
- Takeoff corona treatment: Single-face corona treatment unit, FERRARINI & BENELLI
- Takeoff web guide: E+L

- Rewinder type: TURRET winder, transversal guillotine cut, control device: PLC Siemens
- Rewinder width: 2300 mm
- Rewinder automatic: Yes
- Rewinding type: lay-on roller and contact carriage
- Rewinder reels diameter max: 800 mm

Info:
- In Line Slitting
- Gross output: 350 kg/h
- Automatic hopper loader (without dosing systems)
- Fixed extrusion die 2300 mm
- Manual adjustment
- Air and smoke suction by fan and encapsulating hood
- No. 6 thermoregulation zones
- Lever-type screen-changer
- Single-face corona treatment unit
- Ferrarini & Benelli
- Side-slip unit ERHARDT + LEIMER
- Motor-drrevolver-type winder with lay-on roller and contact carriage
- Transversal guillotine cut
- Max. reel diameter 800 mmiven haul-off unit and trimming group with 4 rotary blades
- Control device: PLC Siemens

(For images, please see next pages)
