For Sale - UM - 6697 - Egan Cast Film Extrusion Line

Specification

Reference Numbers

UM - 6697

Product

Egan Cast Film Extrusion Line

Year Of Manufacture

1985

Location

USA

Product Details

Used Egan cast film line
- Equipped with Process Control resin handling system (3+3)
- Two (2) 3.5" Egan extruders (32:1, 125HP)
- Two (2) Beringer hydraulic screen changers (new in 1995)
- 78" EDI auto-bolt film die (new in 1999, 0.040 std gap)
- Egan 80" 3-roll casting station (16" diameter rolls)
- NDC Beta Gauge (new in 1993)
- Systronics vision system (2cameras, 71" operational width)
- 30" maximum diameter Egan turret rewind (3" shafts)
- And line controls and accessories
- Line was manufacturing film for feminine napkins.
- Web Width: 1880 mm (74 in)
- Size(s): (2) 3.5"
- Rewind Type: Turret
- Speed: 91 MPM (300 FPM)
- Extruder(s): Egan
- L/D: 32:1
- Chill Roll Diameter: 406 mm (16 in)
- Die: EDI
- Die Width: 1981 mm (78 in)
- Max. Diameter: 762 mm (30 in)
- In Operation: No

(For images, please see next pages)
