For Sale - UM - 6895 - Carint 8 Color CI Flexo Printing Machine

Specification

Reference Numbers

UM - 6895

Product

Carint 8 Color CI Flexo Printing Machine

Year Of Manufacture

2001

Location

Europe

Product Details

Model: Miniflex
- Web width (mm): 1250
- Print width (mm): 1200
- Min print repeat (mm): 300
- Max print repeat (mm): 700
- Unwinder type: Turret automatic
- Max reel diameter unwinder (mm): 800
- Rewinder type: Turret automatic
- Max reel diameter renwinder (mm): 800
- Drying: 2 zones, 4 fans, 2 gas burners

- Anilox: 2 x 320 l/cm vol 4,8 ; 290/4,5 vol 4; 200 / 4,5 vol 1; 180/4,8 vol1; 140/7,1 vol2c ; 120/10,4
vol3; 110/12 vol1; 110/13 vol1; 80/14 vol1; 80/17 vol1.

- Print cylinders: 8 x320 mm, 330,340,350,360,370,390,400,420,430,440,460,480,490,500,515,525,540,560,570,600 mm

Additional informations:
- Station with ceramic anilox and closed chamber doctor blades
- Motorized registers
- Material LDPE0, 020 mm-0,150 mm
- HDPE (0,015 mm-0,060 mm; PP (0,020 mm-0,050 mm)

(For images, please see next pages)
