For Sale - UM - 18120 - W&H Novoflex Gearless CI Flexo Printing Press

Specification

Reference Numbers

UM - 18120

Product

W&H Novoflex Gearless CI Flexo Printing Press

Year Of Manufacture

2000

Location

Europe

Product Details

Model:- Novoflex
CI or stack:- Cl
Gearless
Type of inks:- Solventbased
Number of colors:- 8
Max. web width:- 1050 mm
Max. printing width:- 1000 mm
Min. – Max. printing repeat:- 300 - 760 mm
Max. mechanical speed:- 300 m/min
Material & Min – Max thickness:- LDPE, PP, PA 20 – 150 mu
HDPE, OPP 12 – 100 mu Compound film up to 150 mu Paper 30 – 120 g/m2
Unwind type:- Turret with flying splice Shaftless
Max. unwind reel diameter:- 1000 mm
Rewind type:- Turret with flying splice
Max. rewind reel diameter:- 1000 mm
Number & sizes airshafts for winder:- 2 x 76" for rewind
Drying type:- Thermic oil
Heating source included
Edge guide(s)
Video camera
Corona treater AFS
Auto-clean
Inline slitting:- 16
Number of carrier sleeves:- 57
Number of sleeves:- 565
