For Sale - UM - 17191 - Rotomec Rotopak 10 Colors Rotogravure Printing Press

Specification

Reference Numbers

UM - 17191

Product

Rotomec Rotopak 10 Colors Rotogravure Printing Press

Year Of Manufacture

2002

Location

Europe

Product Details

Print possibilities :- 10 col print, 9 col + coating/ cold seal;
Print + Lamination in line;
Print units 1,8,9,10 reversible, unit 9 with 2 lamination units,
Possibility of cold seal in register on unit 10

Drive:- Electronic shaft
Web width (mm):- 1025
Print width (mm):- 1000
Print repeat range (mm):- 500-1000 mm
Max reel diameter unwinder (mm):- 1000
Rewinder type:- Turret two direction
Videocamera:- Eltromat Camera + 100PCT inspection AVT Apollo
Register control:- Eltromat
Corona treatment:- Albrandt
Print cylinders:- No

Additional information:- High performance rotogravure press.
Mechanical Speed 550 m/min Secondary unwinder Turret max diam 1000 mm Lamination unit AC driven.
Roller water heated. Turning Bar
