For Sale - PCM - 2335 - Sheet Plant

- Sheet Extruder contains screw and barrel made from alloy steel duly nitrided and hard chrome plated for long life.
- Screw is fitted on a suitable heavy thrust housing with thrust and roller bearing to withstand thrust pressure during extrusion. - Screw is driven by AC motor and coupled through a suitable standard make gear box. Barrel is divided into three zones for heating load distribution.
- Cooling blowers are provided on the barrel for all zones.
- Water circulating jacket is provided in feeding zone.

Sheet Die:
- Die and adaptor is made out from alloy steel and hard chrome plated.

Calendar Unit:
- This unit having suitable length of rolls made from alloy steel.
- These rolls are precisely grinded and hard chrome plated to get better shining of the sheet.
- These rolls having facility to circulate hot/cold liquid with sliding and lifting arrangements.
- All the rolls are driven by a AC Motor coupled through a suitable gear box.
- Complete unit is fabricated on heavy structure and facilitated with rail & wheel to shift unit from one place to another.
- Heat exchangers with oil tanks and oil pumps are provide to circulate the hot oil through rollers.
- Microprocessor based Digital temperature controllers are provided to control the heat accurately.

Second Godet:
- This unit is used to pull sheet extruded from the die and equipped with specially designed rubber rolls.
- AC Motor of 2 HP capacity is coupled through a suitable reduction gear box to drive the rolls.

Surface Winder or Cutter:
- Surface winder is equipped along with the plant as per the requirements of the customer to suit the application.
- Rubber and Steel rolls are provided for the perfect winding of the sheet.
- These rolls are driven by a 1 KG/Mtr torque motor.

Control Panel:
- Control Panel is comprises of microprocessor based Digital Temperature controllers to control the temperature on barrel and die.
- All AC motors are driven by thyristorised AC drive to get the better speed control.
- Main AC motors get the optimum performance of the machine.

For more details & images please see next pages
