For Sale - PCM - 3211 - Plastic Cup Curling Machine

Specification

Reference Numbers

PCM - 3211

Product

Plastic Cup Curling Machine
Product Details

The machine is suitable for sheet of PVC, PS, PET, and PP etc, to make curling the mouth cup.
The machine is combined with pneumatic, mechanical and electrical system. The machine is achieved to automatic continuous working feeding cup, curling, completed cup and stacking.

Technical parameter:
- Main motor: 1.5KW
- Feeding motor: 0.09KW
- Heating power: 10KW
- Power: 380V, 50Hz
- Air pressure: 0.6Mpa
- Maximum diameter of curling: 120mm
- Maximum speed of curling: 300-400pcs/min
- Overall size: 5200×1100×1300mm3
- Weight: 0.9T

(For picture, please see next page)
