For Sale - PNE - 2086 - Flexographic Printing Machine

XL Plastics Delta Series Models: Superflex 550 / 750 / 950 and Econoflex 550 / 750 / 950
Features:
- Stack type design for easy operation
- Printing speed up to 60 meters/min
- 2,4 and 6 colour printing options
- Two unwind and rewind stands
- Interlock between heaters and blowers
- Print repeats from 8" to 36"
- Unwind roll diameter: Max. 600 mm
- Pneumatic engagement of print cylinders
- Inking rollers rotate and plate cylinders retract when printing is stopped, avoiding drying of ink on rollers and thereby reducing print wastage.

Advantage:
Machines manufactured by XL Plastics are designed for continuous duty and maintenance free operation. These standard features make them more reliable, efficient and operator friendly.

- Heavy duty construction: Rigidly constructed frame gives vibration free operation.

- Fully assembled and pre wired: The machine is shipped in fully assembled and pre wired condition. It comprises of two unwind and rewind stands, stack type printing stations, drying chamber and control panel.

- AC inverter drives: The main motor is AC, with inverter speed control drive for maintenance free operation.

Options:
- Automatic tension control on unwind / rewind with load cell and particle brake with microprocessor control to maintain accurate tension
- Air shaft
- Web aligner

(For more details and picture, please see next pages)
