| Model | BJA 2030 | BJA 2842 | BJA 3248 |
| Max cutting width | 18" | 26" | 30" |
| Max cutting length | 30" | 42" | 48" |
| Film thickness(mm) | 0.009-0.15 | 0.01-0.2 | 0.01-0.2 |
| Length tolerance | ±1mm | ±1mm | ±1mm |
| Production rate(PC) | 36-140 | 36-130 | 30-120 |
| AC Driving motor | 1HP | 2HP | 2HP |
| Heater capacity | 1.8KW | 2.2KW | 2.4KW |
| Power required | 2.8KW | 3.5KW | 4.0KW |
|
Machine dimensions(LxWxH)(cm) |
345x100x140 | 360x120x150 | 360x130x150 |
| Machine weight (kg) | 500 | 650 | 750 |
|
Machine dimensions(LxWxH)(cm) |
273x127x155 | 273x140x164 | 273x164x158 |
| Gross weight(kg) | 700 | 900 | 1000 |
