Specifications:
Description |
Type
/Unit |
PQ-1.5S
|
PQ-1.8S
|
| Screw Diameter |
mm |
22 |
25 |
25 |
28 |
| Injection Capacity |
g |
40 |
48 |
48 |
55 |
| Injection Pressure |
kg/cm2 |
1650 |
1480 |
1480 |
1230 |
| Screw Speed |
r.p.m. |
10-150 |
10-190 |
| injection Rate |
kg/hr |
30 |
35 |
35 |
40 |
| Clamping Force |
ton |
14 |
19 |
| Opening Force |
ton |
6 |
8 |
| Platen size |
mm |
440/280 |
490x310 |
| Between Two Tie Bar |
mm |
265 |
290 |
| Max. Opening Daylight |
mm |
260/220 |
260/220 |
| Min. Mold Thickness |
mm |
80/40 |
80/40 |
| Opening Stroke |
mm |
180 |
180 |
| Ejectors Stroke |
mm |
35 |
35 |
| Max. Pump Pressure |
kg/cm2 |
110 |
140 |
| Pump Motor |
HP/KW |
3/2.5 |
5/3.5 |
| Heater Capacity |
KW |
2.4 |
2.4 |
| Total Wattage |
KW |
4.6 |
6.5 |
| Oil Tank Capacity |
l |
80 |
90 |
| Machine Weight |
kg |
900 |
1050 |
| Machine Size (LxWxH) |
cm |
120x90x 230 |
130x95x 230 |
| Shipping Weight |
kg |
800 |
1200 |
| Shipping size (LxWxH) |
cm |
140x100x215 |
140x105x215 |
|
