MODEL |
GF 45GF 45 |
GF 45-2C |
GF 45-3C |
|||
|
Material |
PP |
PP | PP | |||
| Colour | 1 | 2 | 3 | |||
| Product dia |
m/m dia. |
3-6 | 3-6 | 3-6 | ||
| Product length |
m/m |
125-300 | 125-300 | 125-300 | ||
| Capacity | pc/min | 300-500 | 300-500 | 300-500 | ||
| Extruding output range |
kg/hr |
10-25 | 10-25 | 10-25 | ||
| Screw dia | m/m dia. | 45 | 45 | 25 | 45 | 25x2 |
| Screw i/d | 25 : 1 | 25 : 1 | 25 : 1 | |||
| Motor | HP | VS7.5 | vs7.5 | AC1 | vs7.5 | AC1x2 |
| Heater capacity | Kw | 6 | 10 | 12 | ||
| Speed control | Variable | Variable | Variable | |||
| Automatic thermo-controller | set | 4 | 6 | 8 | ||
| Take up roll | set | 2 | 2 | 2 | ||
| Motor | HP | AC 2x1 set | AC 2x1 set | AC 2x1 set | ||
| Cutter knife | set | 1 | 1 | 1 | ||
| Air compressor | HP | 1 | 1 | 1 | ||
| Total electric used | Kw | 14 | 18 | 21 | ||
| Extruder LxHxW | m | 1.9x1.25x1.65 | 1.9x1.5x1.65 | 1.9x1.6x1.65 | ||
| Vacuum cooling tank LxWxH | m | 2.6x0.5x1.3 | 2.6x0.5x1.3 | 2.6x0.5x1.3 | ||
| Cutting unit LxWxH | m | 1.3x0.65x1.2 | 1.3x0.65x1.2 | 1.3x0.65x1.2 | ||
| Dimensions | LxWxH | 6.8mx1.25mx1.65m | 6.8mx1.5mx1.65m | 6.8mx1.6mx1.65m | ||
| Packing size | inch | 111"x77"x56" | 111"x84"x56" | 111"x87"x56" | ||
| Machine weight | ton | 1 | 1.3 | 1.6 | ||
