Specifications:

Models		LM-300CNT			LM-350CNT			LM-400CNT			LM-450CNT			LM-550CNT			LM-750CNT
Injection unit
Screw diameter	mm	50	55	60	60	65	70	65	70	75	65	75	80	70	80	85	85	90	100
Theorectical injection volume	cm	510	617	734	848	995	1154	1161	1346	1546	1161	1546	1759	1539	2010	2269	2552	3532	3179
Shot weight	g	433	524	623	720	845	980	986	1144	1314	986	1314	1495	1308	1708	1928	2169	2430	3002
(P.S.)	OZ	15.3	18.5	22	25.4	29.8	34.6	34.8	40.4	46.4	34.8	46.4	52.8	46.2	60	68	76.6	85.8	106
Plasticizing capacity (P.S.)	kg/hr	100	124	136	140	164	191	164	200	235	164	235	280	235	280	340	340	350	450
(P.S.)Injection rate	/sec	192	232	277	240	282	327	265	307	353	262	353	402	305	457	516	459	515	636
Injection pressure	kg/c¢T	2237	1848	1553	2245	1913	1650	2226	1920	1672	2226	1672	1470	2250	1722	1525	1936	1727	1398
Screw speed	rpm	0 ~ 180			0 ~ 185			0 ~ 180			0 ~ 140			0 ~ 160			0 ~ 155
Clamping unit
Clamping force	ton	300			350			400			450			550			750
Opening stroke	mm	520			570			625			680			800			950
(Min-Max) Mold thickness (Min-Max)	mm	200 ~ 650			200 ~ 700			200 ~ 750			200 ~ 800			300 ~ 900			300 ~ 1150
Platen size (HxV)	mm	930 x 880			960 x 910			1040 x 990			1090 x 1040			1240 x 1190			1390 x 1330
Distance between tie bar (HxV)	mm	610 x 560			660 x 610			710 x 660			760 x 710			860 x 810			960 x 900
Ejector force	ton	7			7			7			11			11			13.3
Ejector stork	mm	130			150			180			220			240			260
Electrical equipment
Pump motor (HP / 380 / 220V)	HP/A	50/130			60/160			60/160			60/160			75/200			60 x 2/320
Heat zones	set	5			5			5			5			5			6
Heater capacity (380 / 220v)	KW	12.3/56			13.8/63			18.8/85			18.8/85			28.1/128			33.8/154
MAX Ampere (380 / 220v)	A	73/186			88/223			100/245			121/245			143¡£162¡¤/328			185/474
Machine dimension	M	6.8*1.42*1.93			7.0*1.58*2.0			7.7*1.65*2.0			8.0*1.75*2.0			9.6*1.9*2.1			10.6*2.2*2.48
Machine net weight	ton	10.5			13			16			18			24.7			36
