Model |
SQ - 630 |
SQ - 260 |
| Forming platform dimension | 1000 * 1100 (MM) | 700 *500 (MM) |
| Depth(MM) | 200(MM) | 150(MM) |
| Upper Heater |
198 x 0.65 =128.7KW(Upper Heater) 198 x 0.65 =128.7KW(Lower Heater) |
78 x 0.65 =50.7KW(Upper Heater) 78 x 0.65 =50.7KW(Lower Heater) |
| Servo Motor | Feeding-4kw*1 Forming-11kw*1 |
Feeding-2.9kw*1 Forming-7.5kw*1 |
| Water Chiller | 7~10 tons (optional) | 7~10 tons (optional) |
| Air Compressor | 30HP(optional) | 30HP (optional) |
| Machine Dimension | (D)3400 *(H)3300 *(L)13000(MM) | (D)2500 *(H)2700 *(L)8000 (MM) |
| Machine Weight | 8000kg | 5000kg |
