MODEL
|
B-500P-SV
|
B-800P-SV
|
B-1000P-SV
|
Bag
Width (each line) |
450
mm x 1 |
330
mm x 1 |
430
mm x 1 |
Bag
Length (Max.) |
300
~ 700 mm |
300
~ 700 mm |
300
~ 700 mm |
Production
Speed |
120
Meter/min; 200-250 cycle/min |
120
Meter/min; 200-250 cycle/min |
120
Meter/min; 200-250 cycle/min |
Converting
Thickness |
0.010
~ 0.035 m/m |
0.010
~ 0.035 m/m |
0.010
~ 0.035 m/m |
Main
Motor
|
2HP |
2HP |
2HP |
Heater
|
5
KW |
7
KW |
8
KW |
Power
Required
|
7
KW |
10
KW |
12
KW |
Air
Volume & Pressure |
5KG/CM2
500 Ni/min |
7KG/CM2
700 Ni/min |
8KG/CM2
800 Ni/min |
Max.
Reel Diameter |
800 mm |
800 mm |
800 mm |
Dimension
L*W*H (CM) |
650 x 115
x 160 (mm) |
650 x 180
x 160 (mm) |
650 x 200
x 160 (mm) |
Machine
Weight (KGS) |
1800
kgs |
2500
kgs |
2600
kgs |
Packing
L*W*H (CM) |
230 x 120
x 150; 260 x 110 x 176 |
230 x 180
x 150; 360 x 150 x 176 |
230 x 200
x 150; 360 x 200 x 176 |
Gross
Weight (KGS) |
2300
kgs |
2900
kgs |
3100
kgs |
Remark |
1 Photo Cell |
2 Photo Cell |
2 Photo Cell |
* Linear speed
depends on the thickness, the kind of material and size of the bag.
* Air volume & pressure should always keep 5~7 kg/cm2
* Specification subject to change without notice. |
