1.
a) No. 2 reel-holding supports
b) No. 2 reel-holding shafts
c) No. 2 automatic end-of-reel stopping devices.
d) Aluminium cylinders for film insertion
e) Motorized unwinder unit by unwinding cylinder and reduction gear.
f) Oblique compensator equipped with potentiometer for control of film unwinding
g) Supplementary pneumatic compensator
h) Double cylinders for towing film ( with special rubber)
i) Friction rollers with regulation
j) Arrangement for accessories installation
k) Photocell Trolley with regulation.
l) Vertical motorized Compensator for adjusting printing position
m) N.1 Servo-motor for towing film
n) N.1 Servo-motor for bar movement
o) Antistatic, anti-shock bars
p) Additional container for stabilizing pneumatic pressure
q) Air filtering unit with pressure regulator
r) Bulb for automatic pressure control
s) PATENTED BAG STACKING SYSTEM , with double press for formation of bag bundles in pre-set numbers depending on production requirements
t) PATENTED Mechanical bag tearer
2. COMPLETE UNIT FOR BOTTOM WELDING :
a) Bar-holder in special aluminium
b) Upper welding bar made from cast iron profile
c) Pair of resistors for heating the upper profile
d) Temperature probe
e) Rotating Teflon bracket
f) Possibility of rotating the upper bar by 90° for inspection and
maintenance
g) Cutting system with toothed blade
h) Lower bar-holder
i) Lower profile made from special cast iron
k) No. 1 resistor for heating lower profile
l) Temperature probe
m) Rotating Teflon bracket
n) Digital thermoregulators for temperature control and setting.
3. CONTROL AND COMMAND PANEL :
- General computerization of data via digital PC
- Digital keyboard and color monitor for setting and checking production
data
- Programming for bag count for bundles
- Programming bundles count
- Programming production speed
- Programming of welding time
- Programming of trolley positioner parameters
- "on the fly" adjustment of the most important production parameters
without having to stop the machine to reset data
- Continuous visualization of production (bags/min.).
- Automatic self-learning system
- CHECK PANEL for identifying any faults system which thanks
- Luminous column for identifying operating phases
- Warning buzzer for machine start-up
- Main switch : 63 a
Outlet: 3 x 380 + N + T or any other arrangement
- Electrical panel air-conditioning system
- Auxiliary socket for computer connection
- Pre-arrangement for future connection via modem with the manufacturer.
All the mechanical, pneumatic and electrical controls are grouped together on the side of the machine.
4. COLLECTING TABLE WITH PINCES
- Trolley with pincers for extraction of bundles, controlled by the machine's
microprocessor. The trolley is fitted with a last generation system which
thanks to a two-speed control reduce the stopping times for extracting
bundles
- No.1 collection belt with intermittent translation controlled by keyboard
for collecting the finished bundles.
- No.1 console fitted with emergency stop and belt translation controls.
- Collecting table translation system that allows access inside the machine
for maintenance operations.
5. Safety guards and emergency devices foreseen by the CE standards and the laws in force that govern the accident prevention regulations.
