Technical Data   Unit P-15 P-45 Injection Unit       Screw Diameter (M.M.) mm 19/25/28 28/30/35 L/D Ratio L/D 18:1/16:1/14:1 18:1/16:1/14:1 Maximum Swept Volume C.C. 40/54/67 86/90/140 Shot Capacity (Polystyrene) gms/shot 30/40/60 75/100/125 Maximum Inj. Pressure Kg/cm sq. 1900/1100/900 1350/1150/850 Screw Speed Variable rpm 01-190 01-240 Injection Stroke mm 100+10 140+10 Hopper Capacity ltr 5 10 Nozzle Retraction Stroke mm 100 125 Nozzle Contact Force tons 3 5 Clamping Unit Mould Clamping Load tons 15 45 Mould Platen Size mm 345 x 230 400 x 310 Distance Between Tie Bar mm 230 x 115 275 x 185 Maximum Mould Size mm 230 x 230 275 x 310 Maximum Mould Opening mm 150 250 Min/ Max Mould Thickness (Nozzle side) mm 38/100 75/100 Min/ Max Mould Thickness mm 100/200 150/350 Maximum Day-Light Opening mm 350 600 Hydraulic Ejection Stroke mm 40 50 Hydraulic Ejector Force tons 1 1.5 Electricals Pump Motor 3 Phase h.p/k.w. 3/2.25 5/3.75 Heating Load k.w. 3.5 3.8 Installed Total Power k.w. 5.75 7.55 Heat Cont.Polymeter/En.Reg Nos. 3/1 3/1 General Data Floor Space mm x mm 550 x 1100 1500 x 700 Height mm 3000 3200 Weight (approx) tons 1 2.3 Capacity of Oil Tank ltr 70 100
