Technical Specifications Injection Unit Unit P-100 P-125 Screw Diameter (M.M.) mm 30/35/40 35/40/45 L/D Ratio L/D 22:1/18:1/16:1 22:1/18:1/16:1 Maximum Swept Volume C.C. 125/170/225 175/225/290 Shot Capacity (Polystyrene) gms/shot 115/160/210 165/225/270 Maximum Inj. Pressure Kg/cm sq. 2060/1520/1160 1840/1410/1120 Screw Speed Variable rpm 01-240 01-240 Injection Stroke mm 175 180 Hopper Capacity ltr 30 40 Nozzle Stroke mm 150 175 Nozzle Contact Force tons 3 4.5 Pyrometer Nos 4 5 Clamping Unit Mould Clamping Load tons 100 125 Mould Platen Size mm 570 x 520 630 x 560 Distance Between Tie Bar mm 380 x 330 410 x 340 Maximum Mould Size mm 380 x 520 410 x 560 Maximum Mould Opening mm 350 406 Min/ Max Mould Height mm 175/350 200/406 Maximum Day-Light mm 700 812 Ejector Stroke mm 60 75 Ejector Force tons 2.5 2.5 Electricals/ General Pump Motor k.w. 11.25 15 Installed Total Power k.w. 15.85 20 Floor Space mm x mm 3800 x 1200 4200 x 1200 Weight (approx) tons 3 4.1 Capacity of Oil Tank ltr 450 500
