For Sale - UM - 19285 - Battenfeld Cast Film Co-Extrusion Line

Specification

Reference Numbers

UM - 19285

Product

Battenfeld Cast Film Co-Extrusion Line

Year Of Manufacture

1993

Location

Europe

Product Details

Width: 1600 mm
Thickness: 0,08 – 0,8 mm
Control: analogue relay controlled system
Material: PE, PP
Screw Ø: 120 mm,
L/D: 32D,
Motor: 182 kW (DC),
Co-extruder Battenfeld,
Screw Ø: 60 mm,
L/D: 32D,
Motor: 39 kW (DC),
Screen changer,
Melt pump,
Co-ex feed block ABA
Capacity: 500 – 700 kg/h
Downstream: 1.650 mm flat film die,
Polishing stack with 2 rollers,
Cooling track,
Haul-off and double winder
