For Sale - UM - 30951 - Battenfeld HDPE Pipe Extrusion Line

Battenfeld HDPE Pipe Extrusion Line
Running Hours:- 5
Material conveying system
Integration of BCG co-extruder complete display and control of co-extruder from BMC terminal of main extruder
Integration of centralized air supply
Adjustment of fan speed by means of BMCtouch
Recording of temperature difference in the air flow
Synchronization of external drive (0-10 V)
Display and control at BMC terminal of main extruder
Integration gravimetric weighing system a
Display and monitoring of meter weight.
Stabilization of weight per meter by means of haul-off speed control
Volumetric dosing unit for side component
Melt throughput measurement of main component by means of continuous weighing.
Side component by volumetric dosing.
Volumetric dosing unit with storage hopper (content 20 liter)

Hopper scale, KTW-1400-03
Melt throughput measurement by means of continuous weighing
Throughput rate 1400 kg/h

Co-extruder, BCE 1-30-25D
stand-alone machine
Synchronization with main extruder via CANopen, DSP 420 V2.0
Height adjustable via 4 spindles
Moveable on 4 rolls
Vertically swivel-mounted by +/- 5°
Barrel, nitride
Thermocouple bores M14 x 1.5
Melt pressure- and melt temperature transducer
AC-drive incl. gearbox
Screws, nitride
BMCeco operating terminal
a product of battenfeld-cincinnati branch China
