For Sale - UM - 33509 - PET Stretch Blow Moulding Machine

1. RO Plant — Wytewater
Manufacturer Wytewater Technologies Pvt. Ltd., Pune, India
Model / Reference WWT/MW/6000-08
Capacity 6,000 LPH nominal
Year purchased 2009
Process scope Raw-water UV, alkali dosing, pressure sand filter, activated carbon filter, bag and micron filtration, ultrafiltration, RO, ozonation, product-water storage and filling interface

2. Filling Machine — Hilden
Year manufactured / purchased May 2009
Manufacturer Hilden
Model RFC-12/12/4
Speed (BPM / BPH) 60 BPM
Filling volume range 100 ml – 2,000 ml
Rinsing / Filling / Capping heads 12 / 12 / 4
Input conveyor length Conveyor height stated as 900 ± 50 mm.
Additional line equipment The Hilden machine is an automatic 3-in-1 rinser-filler-capper. No inspection table, collection table, heat shrink or cap elevator is confirmed in this machine specification.
Compressed air 3 kg/cm²

3. Filling Machine — Jaisat
Year manufactured / purchased Purchased 2021
Manufacturer Jaisat / Jai Sat Packaging
Model Automatic RFC 18/24/09
Speed 120 BPM / 7,200 BPH at 1 L
Filling volume range 200 ml – 2,000 ml PET
Rinsing / Filling / Capping heads 18 / 24 / 9
Input conveyor length 4 m air conveyor
Output conveyor length 6 m bottle conveyor
Additional line equipment 4 m air conveyor and 6 m filled-bottle conveyor
Connected load 6.5 kW; approximately 8.72 HP
Compressed air 5 kg/cm²
Conveyor height / machine footprint Conveyor height 900 ± 50 mm; footprint 2,800 × 2,200 × 750 mm

4. PET Stretch Blow Moulding Machine — SBR
Year manufactured / purchased Purchased 2021
Manufacturer SBR
PET stretch blow moulding Yes
Capacity Up to 5,400 bottles/hour for bottles up to 1,000 ml; up to 2,400 bottles/hour for bottles up to 2,000 ml
Cavities 4-cavity output for up to 1 L; 2-cavity output for up to 2 L
Mould size / number of moulds Maximum container stated as 2,000 ml, Ø110 mm × H340 mm.
Blowing pressure / chiller 35 bar with air recovery system; integrated 5 TR chiller
Included accessories Auto preform loader, take-off unit and UPS listed

5. PET Stretch Blow Moulding Machine — J.P. Machinery
Year manufactured 2017
Manufacturer J.P. Machinery
Model JP-250-6B
PET stretch blow moulding Yes
Capacity 5,000–5,400 bottles/hour
Bottle volume range 50 ml – 250 ml
Number of cavities 6
Mould size / number of moulds Neck diameter 25–31 mm stated.
Heater specification Infrared heater
Blowing / working air pressure 30 kg/cm² blowing air; 8.5 kg/cm² working air
Chiller / clamping force 5 TR chiller; 15-ton clamping force
Connected load 13 kW

6. Compressor — Comptech
Year manufactured 2021
Manufacturer Comptech
Model CTSD 75
Type Single-stage rotary screw compressor; air-cooled
Power 75 HP (approximately 55.9 kW calculated conversion)
Power supply AC, three-phase
Air delivery 356 CFM at 8 kg/cm²; 321 CFM at 10 kg/cm²
Speed 2,900 RPM

7. Storage Tanks
Total number of tanks 3
Capacity of each tank 6 KL
Material of construction SS 316 (stainless steel)
Year manufactured 2009

8. Chiller
Year manufactured 2009
Manufacturer In-house manufactured by Suneer Enterprises
Capacity 8 TR
Water flow 5 LPH
