Reference Numbers
UM - 22473Product
DMT BOPP Film Extrusion LineYear Of Manufacture
2004Location
Europe
Material:-PVC for shrink labels
Width (mm):-2500
TDO description
Inlet with 450-1000 mm, outlet after stretching 1600 - 2800 mm width; final width after trimming 2500 mm; stretching ratio 1:2 - 1:5; chain type heavy duty lubrificated 60 mm pitch; clips 120 mm pitch; feed zone 1,5 m, pre-heating 2 x3 m, stretching 2 x 3 m, neutral 1 x1 m, cooling/annhealing 6 x 2 m outlet 1 x 1.5 m. 5 independent fans, number of centract joins 5, temperature 60/200 C
Pull roll unit with trimming
Rewinder width:-2500 mm
Rewinder description Turret automatic rewinder
Additional information
Composed of: unwinder TDO unit Turret automatic unwinder
