For Sale - UM - 17849 - Bielloni 3 Layer Cast Film Extrusion Line
Specification
Reference Numbers
UM - 17849Product
Bielloni 3 Layer Cast Film Extrusion LineYear Of Manufacture
2000Location
EuropeProduct Details
Number of layers: 3
Film structure: A-B-C 10/70/20
Material: Stretch 17-24 my
Film width (mm): 2000
Speed (m/min): 260 m/min
Output (Kg/h): 690 Kg/h netto
Extruder 1 Layer ref: : 80/30
Screw diam: 80
Extruder 2 Layer ref: : 160/30
Screw diam: 160
Extruder 3 Layer ref: : 80/30
Screw diam: 80
Head description: T-die and feed block Simplast with manual gauge correction
Die width (mm): 2500
Chill roll unit: 1000 + 400 mm
Thickness controll system: Electronic System Beta rays
Web guide: Yes
Rewinder max reel diameter (mm): 800
Rewinder description: Pheripherical with automatic core glueing and shaft extracting device
