For Sale - UM - 17523 - Dolci 7 Layers Cast Film Extrusion Line

Specification

Reference Numbers

UM - 17523

Product

Dolci 7 Layers Cast Film Extrusion Line

Year Of Manufacture

2012

Location

Europe

Product Details

Model:- UZ 4211
Material:- Thicknes 8 my – 40 my
Film width (mm):- 2000
Speed (m/min):- 700 m/min
Output (Kg/h):- 1300 Kg/h
Screw diam:- 65
Screw diam:- 100
Screw diam:- 160
Screw diam:- 75
Screw diam:- 65
Head description:- Cloeren 7 Layer
Die width (mm):- 2550 mm
Chill roll unit:- Eurochiller
Thickness controll system:- Yes, Scantech
Rewinder max reel diameter (mm):- 2000 mm
Additional information:- 5 extruders + trimm extruder
2 dosing units per extruder - Inno Plast
Cloeren feed block and Die
Tria system for trimm
Rewinder: Dolci Bieloni FCL
Water cooling motors and gearboxes
