For Sale - UM - 24364 - 850 Ton Injection Molding Machine
Specification
Reference Numbers
UM - 24364Product
850 Ton Injection Molding MachineLocation
CoimbatoreProduct Details
Model : IS850GTW
Clamping Force : kN 8330
Mold Opening Froce : kN 634
Distance Between The Rods (H x V ) : mm 1265x1265
Platen Dimensions (HxV) :mm 1735x1735
Clam stroke :mm 1750
Open Day Light (Maximum) : mm 2250
Closed Day Light : mm 500-1100
MOLD CLOSING SPEED :
Fast m/min : 2.4-42.9 /(2.0-35.7)
Slow m/min :2.0-3.0
MOLD OPENING SPEED :
Fast : m/min :2.4-41.2 /(2.0-34.3)
Slow : 2.0-5.0
Ejecting force (Hydrulic) :kN 242
Ejecto stroke :mm 200
