For Sale - UM - 24410 - Battenfeld 450 Ton Injection Molding Machine

Specification

Reference Numbers

UM - 24410

Product

Battenfeld 450 Ton Injection Molding Machine

Year Of Manufacture

2001

Location

Europe

Product Details

Machine Type :TM4500/2800
Working hours:78072

Closing unit
Clamping force [kN]:4500
Dimensions of mounting plates (hxv) [mm]:1155x1195
Clearance between columns (hxv) [mm] : 800x800
Min./max. mold height [mm]:min 425/max 770
Maximum opening width [mm]:1530

Injection unit
Screw diameter [mm]:75
Injection volume [cm3]:1657
Injection weight [g] 1506
Injection pressure [bar]:1739
