For Sale - UM - 18110 - Krauss Maffei 150 Ton Injection Moulding Machine

Specification

Reference Numbers

UM - 18110

Product

Krauss Maffei 150 Ton Injection Moulding Machine

Year Of Manufacture

1999

Location

Europe

Product Details

Type of machine: KM 150 - 700 C2
Clamping force: 1500 kN
Mould opening force, max.: 86 kN
Travel force movable platen Opening: 45 kN
Travel force movable platen Closing: 34 kN
Size of mould platens (h x v): 840 mm x 790 mm
Distance between tie bars (h x v): 560 mm x 500 mm
Mould opening stroke: 600 mm
Mould height min.: 300 mm
Max daylight: 900 mm
Hydraulic ejector - stroke: 150 mm
Ejector force forward/backward: 20/11 kN

This unit has brand new injection chamber.
