For Sale - UM - 19325 - Ofem Appia FDS 8 Colors CI Flexo Central Drum Printing Press
Reference Numbers
UM - 19325Product
Ofem Appia FDS 8 Colors CI Flexo Central Drum Printing PressYear Of Manufacture
2005Location
Europe
Number of colors:- 8
Print possibilities:- 8+0
Fast sleeve change
4 motor per deck CNC position system
Computer supervision
Web width:- 1250 mm
Print width:- 1200 mm
Min print repeat:- 370 mm
Max print repeat:- 800 mm
Unwinder type:- Double position with drop splice
Max reel diameter unwinder:- 1000 mm
Rewinder type:- Turret automatic
Max reel diameter rewinder:- 800 mm
Drying:- 2 zones 4 fans , final tunnel 4 mt , 2 gas burners
Videocamera:- BST Power scope 3000
Web guides yes BST in and out
Vyscosity control 5 visco Controls Gama S25
Inking system:- Closed chamber doctor blades ( 8 + 2 spare ) , 8 pneumatic ink pumps double diaphragm
Anilox:- Nr. 3x 320 l. / v. 4,5; 2x 180 l. / v. 8; 2x 140 l. / v. 10; 1x 100 l. / v. 20
Print Sleeves:- 160 sleeves complete with gears 8 for each repeat 370 , 380 , 390, 400, 410, 420, 430, 440, 450, 460, 480, 500, 510, 530, 540, 580, 600, 650, 700, + 2 x 750, +2 x 70'
Additional information:- Materials : Paper , PP, PP cast, PET, LDPE, HDPE, BOPA, Aluminium
