For Sale - UM - 11356 - UTECO 9 Colour CI Flexo Printing Machine

- Model: EMERALD 825 SYNCHRO (GEARLESS)
- Number of colors: 9
- Print possibilityes: 8+1 , 8+0, 9+0
- Gearless: Yes
- Fast sleeve change: Yes
- 4 motor per deck CNC position system: Yes
- Computer supervision: Yes
- Web width (mm): 1350
- Print width (mm): 1300
- Min print repeat (mm): 350
- Max print repeat (mm): 800
- Unwinder type: TURRET AUTOMATIC
- Max reel diameter unwinder (mm): 1000
- Rewinder type: TURRET AUTOMATIC
- Max reel diameter renwinder (mm): 1000
- Drying: Gas burners drying system.
- Videocamera: Yes
- Corona treatment : Ferrarini & Benelli
- Web guides: Edge guide at press infeed OPG ; edge guide at press outfeed Shifting ;
- Vyscosity control: 8 viscosity controls brand Fasnacht
- Washing system: Automatic washing system
- Inking system: 8 ink trays
- Anilox: 24 ceramic anilox
- Print Sleeves: 8
- Number of printing stations 8+1 .Downstream unit for varnishing. Printing
repeat with additional software extracost 2.200 Euro.Mechanical speed : 350m/min.Materials :
film & paper
- Type of ink used water & solvent based inks.Reels loading /unloading motorized
system.
- Banana roller
- Cutting knife system
- Blade & circular knives, Trim exhauster, Replace heypad. Motorized
longitudinal register control
- Motorized side register control. Automatic pre-register. Job recipes
- Infeed nip roller diam 195mm for low tension control
- Possibility for insetting/reprint system Out- feed unit
- 1 cooling and feed chill roll. Pneumatic dancing roller for web tension on unwinder and rewinder
- Downstream one colour " Coral" stack unit. The stack unit can use both normal gas drying system and UV system
- The unit is equipped with Grafikontrol register control.
- 3 UV lamps installed on the outfeed chill roller , 450mm diam.Ancillary equipment supplied with
the machine : Nr. 8 closed chamber doctor blades, teflon coated
- New accessories included :8 ink pumps with tanks and hoses ;4 ceramic anilox sleeves Praxair 340 l / cm vol 3,6 ; 13
sets of print sleeves 8 for = 104 each of following repeat (in mm.) 350 , 380 , 400 , 420 ,
430 , 450 , 500 , 550 , 600 , 660 , 700 , 750 , 800 ; 2 sets =16 of Carbon fiber carriers base
repeat 500 and 650 mm

(For more details and images Please see Next pages)
