For Sale - UM - 13885 - Zocchi 3 Layer Co-Extrusion Line

Specification

Reference Numbers

UM - 13885

Product

Zocchi 3 Layer Co-Extrusion Line

Year Of Manufacture

1998

Present Condition

Machine is in very good working condition

Location

Europe

Product Details

For blown stretch film in bubble
Screws diam. 70-100-70 mm. Ratio 30 L/D
New screws and barrels
4/6 components Maguire Blending Systems on each Extruder
N.3 screen changers
Oscillating die 750 mm.diam.
IBC, dual flow airring
Calibration cage
Take off unit 3000 mm. wide
Secondary nip rollers with slitting station
Back to back winding station 2800 mm. wide. automatic control of tensioning
Trim recycling system
Air shafts and unloading reel system
Ouput on Stretch 20 microns 350 kg/hr
LDPE materials 600 kgs p/hr
