For Sale - UM - 2417 - Comexi 6 Colours CI Flexo Press
Reference Numbers
UM - 2417Product
Comexi 6 Colours CI Flexo PressYear Of Manufacture
1994Location
Europe
Model: FS 1500/6- 120
- System: Geared
- Printing width: 1220 mm
- Web width: 1270 mm
- Printing repeat (max): 900 mm
- Printing repeat (min): 300 mm
- Plate-cylinder gear-pitch module: 10 mm
- Plate-thickness, sticky back included: 3 mm
- Drying system: Electrical
Other specs:
- Mechanical speed: 250 m/min
- Distance between printing deks: 786 mm
- Max thickness of the cliche including the adhesive: mod. 3 mm
- Roll diam unwind/rewinder: 800 mm
- Core diam. 76 mm
- Water pressure needed: 2 ATM at 18 Degree C
- Central drum diam. 1500 mm
- Longitudinal register on the colours by micrometric screws that sidely moves the gear of the printing cylinder. Regulation: 14mm
- Side register on the colours by micrometric screws that sidely moves the axel of the printing cylinder. Regulation: 15 mm
- Drying between colours and on the drying tunnel.
(For more details and images, please see next pages)
