For Sale - UM - 6958 - Colines 3 Layers Cast Film Line
Reference Numbers
UM - 6958Product
Colines 3 Layers Cast Film LineYear Of Manufacture
1998Location
Europe
- Model: COEX
- Film structure: ABC
- Material: Streuture / LDPE - LLDPE
- Film width (mm): 1500
- Extruder 1 layer ref: A
- Screw diameter: 80
- Extruder 2 layer ref: B
- Screw diameter: 130
- Extruder 3 layer ref: C
- Screw diameter: 80
- Thickness control system: Thickness control electronic systems X RAY Rewinder max reel diameter (mm): 500
Additional informations:
- Production of jumbo rolls of stretch film
- trims recycling system in line
- Cart board cores internal diameter 76 mm
- Max mechanical line speed: 550 m / min
- Production capacity: 550 kg / hr (450 m / min -15 my)
- 840 kg / hr (450 m / min -23 my)
- Thickness range: 15 to 50 my
- Installed power 700 KW
- Consumption: 0,5 KW / kg (total consumption 350 KW)
(For images, please see next pages)
