For Sale - UM - 6977 - Andreotti 8 Color Rotogravure Printing Machine

Model: Rotostar
- Print possibilities: 7 colors + lamination in line
- Web width (mm): 1400
- Print width (mm): 1250
- Print repeat range (mm): 400-900
- Drying specifications: double hoods: 1 & 2, mm 4000
- Single dryer hoods: 3, 4, 5, 6 , mm 2000
- Double dryer hoods on print units: 7 & 8 mm 4000
- All units with independent ventilation.
- Drying heat source: Diathermia oil heater with gas burner1.000.000 Kcal Union select year 2006
- Unwinder type: Non stop turret unwinder
- Max reel diameter unwinder (mm): 1200
- Rewinder type: Non stop central-surface type rewinders
- Max reel diameter renwinder (mm): 1200
- Video camera: Yes

Register control:
- 1 color register control model: CR33 Grafikontrol year 2007
- Vyscosity control: 8 automatic viscosity control, year 2007
- Print cylinders: 500

Additional informations:
- 1 coating unit for reverse side or solvent lamination application (8), 1 exiting driving colander
- 1 non stop turret unwinder for solvent lamination application (8), mm 600
- 1 control system
- Fife web guide ring for non stop turret unwinder
- 4 pneumaticalexpanding shafts
- 152 mm
- Fife web guide ring non stop turret unwinder for solvent lamination application
- 9 flameproof electric pumps
- 10 doctor blades
- 16 speedwell sleeves
- Fire alarm system Co2, year 2007
- Solvent system
- Air system for speedwell sleeves changing, 8 diathermia Oil Thermal with temperature control, year 2007
- Web viewing and control of the printing quality genius BST year 2007
- 1 soundproofed wall
- slitter rewinder TLTC

(For images, please see next pages)
