For Sale - UM - 8156 - Toyo 55 ton Injection Molding Machine

Specification

Reference Numbers

UM - 8156

Product

Toyo 55 ton Injection Molding Machine

Year Of Manufacture

1998

Location

Canada

Product Details

Model: Ti-55H
- Shot size: 2.7 oz
- Screw diameter: 1.26"
- Clamp stroke: 10.6"
- Min / max mold height: 5.91" / 12.6",
- Tie bar distance: 12.8" x 12.8"
- Platen size: 18.11" x 18.11"
- Injection stroke: 3.94"
- Ejector stroke: 2.36"
- Options: Core Pull
- Hydraulic K.O.
- Robot Interface

(For images, please see next pages)
