For Sale - UM - 22082 - Acom Comexi Gravure Printing Machine
Reference Numbers
UM - 22082Product
Acom Comexi Gravure Printing MachineYear Of Manufacture
2017Location
Europe
Number of colors:-6
Print possibilities:-6+0 , 5+1
Drive:-Electronic shaft
Trolley system:-Yes
Web width (mm):-1050
Print width (mm):-1030
Print repeat range (mm):-450 - 920
Drying specifications:-Units 1- 5 single hood 1,8mt, unit 6 double extended hood 2 x 2,2 mt
Drying heat surce:-Thermo oil heat exchanger
Unwinder type:-Turret automatic
Max reel diameter unwinder (mm):-1000
Rewinder type:-Turret automatic
Max reel diameter rewinder (mm):-1000
Videocamera:-BST ELTROMAT Web video Eltromat 500
Register controll:-ELTROMAT ( with reading heads with possibility to read triangular marks 10x6)
Vyscosity control:-YES
Corona treatment:-AHLBRANDT
Additional information:-
Mechanical speed 350 m/min - Max width for print cylinders 1100 mm - 2 x 76 mm shaft, 4x 152 mm shafts - Elecctrostatic assistance Enulec on 6 print units + anti static bars on un and rewind - LEL system make MSA, IR sensors Turning bar before 6th station OPTION Additional gravure coating unit Acom
