For Sale - UM - 17459 - Rotomec Rotopack 8 Colors Rotogravure Printing Press
Reference Numbers
UM - 17459Product
Rotomec Rotopack 8 Colors Rotogravure Printing PressYear Of Manufacture
2004Location
Europe
Print possibilities: 8+0 print plus coating.
Unit 8 reversible. Turning bar on unit 8
Overhaul/renovation: 2007
Drive: Electronic shaft
Trolley system: Yes
Web width (mm): 1020
Print width (mm): 1000
Print repeat range (mm): 350 - 800
Drying specifications: 8 independent drying section 8 blowing fans , one general exhaust oil
heated, unit 1 double, unit 2-7 single, unit 8 double extended
Drying heat surce: thermo oil
Unwinder type: Turret shaftless
Max reel diameter unwinder (mm): 1000
Rewinder type: Turret shaftless
Max reel diameter rewinder (mm): 1000
Videocamera: video camera BST, sperarte quality control Noreco
Register controll: yes Eltromat
Corona treatment : Yes , shermann
Print cylinders: sleeve type gravure
Additional informations: PLC Siemens S 7
Gearless inverters and motors Siemens
2x web guide
16 trolleys
Lel control system
Speed 350 mpm
